TSG 3800

$1,751.00

Data Sheet

TSG-3800

23478272-004-0

Refurbished and guaranteed for 90 days.

Both the 3800 and the 3800E are timing signal generators that generate and distribute network synchronization signals. Input signals can be DS1, E1, 2048 kHz, sinusoids, or square waves. The TSG-3800E and optional TSG-3800EX Expansion shelf are EMC-compliant, 19-inch, rack-mounted systems with a special metal chassis incorporating elements to reduce electromagnetic interference (EMI) emissions.

The TSG-3800 User Guide contains information about installing, configuring, operating, and maintaining the TSG-3800 Timing Signal Generator systems manufactured by Symmetricom. The TSG-3800 series of products are available in three versions:  TSG-3800 19-inch Main Shelf and an optional 19-inch Expansion shelf

TSG-3800E 19-inch electromagnetic compatibility (EMC) compliant Main Shelf and an optional 19-inch EMC compliant Expansion shelf

TSG-3800 23-inch Main Shelf and an optional 23-inch Expansion shelf

Features Common to All Models

  • The TSG-3800 series has three main shelf assemblies that share the following common features:
  • External connections on the rear panel
  • Up to 12 input reference signals
  • Generation of output signals (optional Expansion shelves are available for additional outputs)
  • Power subsystems
  • External alarm connections
  • Controls and indicators
  • Module functionality – the TSG-3800E uses a set of EMI-compliant modules that are functionally

Description

TSG-3800

23478272-004-0

The TSG-3800 family of Timing Signal Generators was originally manufactured by DATUM and is made up of a 3800 master shelf and accompanying expansion shelf. They are timing signal generators that generate and distribute network synchronization signals. Input signals can be DS1, E1, 2048 kHZ, sinusoids, or square waves.

Syncworks warehouses and ships Microchip products and retired sync and timing equipment from Symmetricom, Telecom Systems, Datum, Microsemi and more. Our Field Services team will install and enable your sync and timing equipment. Our SyncCare will provide peace of mind in the event of any issues.

Features Common to all Models:

  • Up to 12 input reference signals
  • Power Subsystems
  • Module Functionality- The TSG 3800E (19″ shelf) uses a set of EMI- compliant modules that are functionally identical to the modules available in the TSG-3800 (23″ shelf)
